What is the default IEEE 802.1x AP authentication configuration on a Cisco Catalyst 9800 Series Wireless Controller?

A. EAP-PEAP with 802.1x port authentication

B. EAP-TLS with 802.1x port authentication

C. EAP-FAST with CAPWAP DTLS + port authentication

D. EAP-FAST with CAPWAP DTLS

When implementing self-registration for guest/BYOD devices, what happens when an employee tries to connect four devices to the network at the same time?

A. The last device is removed and the newly added device is updated as active device.

B. The registration is allowed, but only one device is connected at any given time.

C. All devices are allowed on the network simultaneously.

D. Purge time dictates how long a device is registered to the portal.

An engineer is implementing Cisco Identity-Based Networking on a Cisco AireOS controller. The engineer has two ACLs on the controller. The first ACL, named BASE_ACL, is applied to the corporate_clients interface on the WLC, which is used for all corporate clients. The second ACL, named HR_ACL, is referenced by ISE in the Human Resources group policy. What is the resulting ACL when a Human Resources user connects?

A. HR_ACL appended with BASE_ACL

B. HR_ACL only

C. BASE_ACL appended with HR_ACL

D. BASE_ACL only

Where is a Cisco OEAP enabled on a Cisco Catalyst 9800 Series Wireless Controller?

A. RF Profile

B. Flex Profile

C. Policy Profile

D. AP Join Profile

Which role does an engineer configure for administrative access to the wireless infrastructure, using Cisco ISE, to allow configuration of the WLC syslog configuration?

A. MANAGEMENT

B. SECURITY

C. CONTROLLER

D. WIRELESS

A wireless administrator receives this information to complete a CMX deployment in high availability by using version 10.6 to gather analytics. IP address of the primary server IP address of the secondary server failover mode to be configured as automatic root password of the secondary server email ID for NOC notifications Enabling high availability fails when these parameters are used. Which action resolves the issue?

A. Insert the cmxadmin password of the secondary server.

B. Use IP protocol 4242 for the controller to reach the CMX server.

C. Place primary and secondary servers in different subnets.

D. Enable the virtual IP address of the primary server.

An engineer is using Cisco Prime Infrastructure reporting to monitor the state of security on the WLAN. Which output is produced when the Adaptive wIPS Top 10 AP report is run'?

A. last 10 wIPS events from sniffer mode APs

B. last 10 wIPS events from monitor mode APs

C. last of 10 sniffer mode APs with the most wIPS events

D. last of 10 monitor mode APs with the most wIPS events

A network engineer is deploying 8865 IP phones with wireless clients connected to them. In order to apply the appropriate QoS, the IP voice traffic needs to be distinguished from client data traffic. Which switch configuration feature must be enabled?

A. WME

B. QBSS

C. Voice VLAN

D. QoS routing

What is the Cisco recommended configuration for a Cisco switch port connected to an AP in local mode for optimal voice over WLAN performance with an 8821 wireless phone?

A. switchport encapsulation dot1qswitchport mode trunkmls qos trust device cisco-phone

B. switchport mode accessmls qos trust device cisco-phone

C. switchport mode accessmls qos trust cos

D. switchport mode accessmls qos trust dscp

Refer to the exhibit.

Which COS to DSCP map must be modified to ensure that voice traffic is tagged correctly as it traverses the network?

A. COS of 6 to DSCP 46

B. COS of 3 to DSCP 26

C. COS of 7 to DSCP 48

D. COS of 5 to DSCP 46
