Refer to the exhibit.

Which port has a fixed IP and subnet mask?

A. A

B. B

C. C

D. D

E. E

What software is used to assign IP addresses when installing a new CLARiiON?

A. Unisphere Initialization Utility

B. Unisphere Server Utility

C. Unisphere Service Manager

D. Unisphere Client

Which Unisphere dialog allows users to configure the amount of write and read cache for SPB?

A. Storage System Properties, SP Memory tab

B. Storage System Properties, SP Cache tab

C. SPB Properties, General tab

D. Storage System Properties, General tab

What role should be applied to allow only SnapView operations?

A. Local Replication

B. Replication

C. Replication and Recovery

D. Monitor

Where does the physical WWN seed name reside on a CLARiiON?

A. Resume PROM

B. PSM LUN

C. SP HBA PROM

D. Vault drives

The Access Logix ACL entries consist of the CLARiiON SP port WWN and which other two elements?

A. LUN UID and Host HBA WWN

B. LUN UID and Host HBA WWPN

C. LUN HLU and Host HBA WWN

D. Host SID and CLARiiON serial number

Which hardware component is used to offload iSCSI and TCP processing from the host CPU?

A. iSCSI host bus adapter (HBA)

B. Dual NICs

C. NIC TCP Off-load Engine (TOE)

D. NIC

An existing CLARiiON array running release 26 FLARE code is being converted to a CX4 and release 30 FLARE code. You discover clone LUNs are in use on the existing array. What must be done before the conversion?

A. Change the CPL size from 128 MB to 1GB.

B. Change the CPL size from 128 MB to 256 MB.

C. Change the CPL size from 256 MB to 128 MB.

D. Change the CPL size from 128 MB to 512 MB.

Use the calculator.

A customer has an application that processes large graphics files. The application reads raw graphical data, writes temporary files that are the size of the original data, and overwrites the temporary files with final data that is the same size as

the original data.

The remaining temporary data is then deleted. The 800 GB data LUN has a single SnapView session, which is started before processing begins, and is removed after processing ends.

If the original data for a given run was 250 GB in size, how much space is required in the reserved LUN pool?

A. 255 GB

B. 375 GB

C. 510 GB

D. 755 GB

Use the calculator.

A customer has an application that processes very large medical image files. The application reads raw graphical data, writes temporary files that are 200% of the size of the original data, and writes final data that is the same size as the original data. The temporary data is then deleted. The 1000 GB data LUN has a single clone, which is fractured before processing begins, and is resynchronized after processing ends.

If the original data for a given run was 250 GB in size, how much data is written to the clone when it is resynchronized?

A. 750 GB

B. 500 GB

C. 250 GB

D. 1000 GB
