What are three reasons a BGP route would be hidden? (Choose three.)

A. The AS Path contains a 0.

B. It is suppressed by a damping policy.

C. The Local Preference is 0.

D. The next hop is unreachable.

E. It is rejected by a firewall term.

Which two statements about Layer 2 loop prevention protocols are correct? (Choose two.)

A. RSTP distributes the current tree topology using the root bridge.

B. STP can take 30 to 50 seconds to respond to a topology change.

C. RSTP can take 30 to 50 seconds to respond to a topology change.

D. STP distributes the current tree topology using the root bridge.

What are three types of port designation specific to Private VLANs? (Choose three.)

A. Promiscuous ports

B. Transparent ports

C. PVLAN trunk ports

D. Designated ports

E. Isolated ports

You are running a Virtual Chassis with nonstop routing enabled. You want to confirm that the BGP routing table synchronization has completed on the backup Routing Engine.

Which command will show you this information?

A. show task replication

B. show bgp summary

C. show bgp neighbor

D. show bgp replication

On EX Series devices, what are two software features that accommodate redundancy? (Choose two.)

A. OAM

B. NSR

C. IGMP

D. GRES

Click the Exhibit button.

Referring to the exhibit, which router will be selected as the DR?

A. R1

B. R5

C. R4

D. R3

Referring to the exhibit, which two statements are correct? (Choose two.)

A. R2 and R3 can form a Level 1 IS-IS adjacency.

B. R4 and R5 can form a Level 1 IS-IS adjacency.

C. R1 and R5 can form a Level 1 IS-IS adjacency.

D. R3 and R4 can form a Level 2 IS-IS adjacency.

Which two statements about RSTP are correct? (Choose two.)

A. RSTP is backward compatible with STP.

B. RSTP permits multiple root bridges within a Layer 2 domain.

C. RSTP permits only a single root bridge within a Layer 2 domain.

D. RSTP is not backward compatible with STP.

Click the Exhibit button.

Which type of route is shown in the exhibit?

A. generated

B. direct

C. aggregate

D. static

Click the Exhibit button.

A routing table contains multiple BGP routes to the same destination prefix. The route preference is the same for each route.

Referring to the exhibit, which route would be selected?

A. route B

B. route D

C. route A

D. route C
